Nov 3rd 2016: RX MLink Software Update Now Available:

- Support added for RX firmware version 1.77
- Support added for Smart TCB board
- Minor GUI changes
- Updated user manual
- Updated help file

Download

Nov 3rd 2016: RX User Manual v6.8 Now Available:

Click here for more information on the Motortronics RX documents


Jun 1st 2016: Introducing VMX S.A.F.E.



The New Standard of Safety for Electricians
The VMX S.A.F.E. Series is the ultimate product in the market today for Low Voltage Control which allows a Service Engineer / Electrician to do the job safely with minimum PPE.

S.A.F.E Voltage Compartments
The S.A.F.E control has a low-voltage compartment which has limited energy 120 Vac signals available. All the control logic is in the isolated Low Voltage compartment along with a three phase 120 Vac test point for the primary voltage sensing and measuring. All keypads, meters, lights, relays and control logic are available in the low-voltage compartment. No need to open the high-voltage compartment to check control logic and status.

The 65 kA breaker at 480 Vac and surge device are located inside the side enclosure for safety. S.A.F.E. has a LED live voltage indicator connected to the output of the main breaker. The visual voltage indication would guarantee the breaker is open and no voltage is present before entering the larger Soft Start enclosure.

The service engineer or electrician can safely enter the large enclosure knowing that no voltage is present and limited PPE is required. An isolation contactor is standard on all S.A.F.E. units so when the motor is off no voltage will be present on the motor leads. Safe for anyone working on the motor, equipment or soft starter control enclosure. Visual live line indication ensures the safety for all Service engineers and Electricians during lockout / tag out procedures.

S.A.F.E. Protection Features
All S.A.F.E. units come with flanged mount lockable breaker which interlocks with both the side safety breaker box and the main soft start enclosure. The VMX S.A.F.E. Series also comes with redundant motor protection. Should the customer need a little extra torque and want to start the motor across the line the contactor and a full digital redundant motor protective relay (Rx Series) is available to protect the motor while performing an across the line start without the Soft Starter. Option NEMA contactors are also available for long life. Both the Soft Start VMX and the Rx relay utilize true thermal modeling to ensure optimal motor protection and performance. When safety, long life and reliability is key and only the best will do --- choose -- S.A.F.E. Series the ultimate protection for Engineers / Electricians and Equipment.



Download VMX S.A.F.E. Brochure (PDF, 1.02 MB)


May 16th 2016

Motortronics launches new major MLINK software update for their MVC, DXT, VMX, RX and TE-RTD12 product series.


DXT MLink

Download

MVC MLink

Download

VMX Mlink

Download




RX MLink

Download

TE_RTD12 Mlink

Download



What's New in version 2.5.0.0:

- Upgraded user interface with improved navigation
- Improved Communication
- Updated report generator
- Updated e-mail engine
- Updated help file
- Optimized for Windows 10
- Updated auto-update function
- Functionallity added to open trend file with file open in main menu
- Phase Currents and Voltages added to Event log
- Minor improvements and fixes

  • System Requirements
  • Computer with Intel® Core i3 or equivalent processor.
    Microsoft® Windows® 7 or higher with latest service pack.
    2GB or more recommended.
    Minimum screen resolution of 1024 x 768 (1280 x 800 recommended).
    100 MB of available disk space.
    Mouse or other pointing device.
    Inkjet or laser printer for printing of reports.
    E-mail with Messaging Application Programming Interface (MAPI) to e-mail reports.
    Internet Connection to download software updates.
    Ethernet or serial port.

April 2016: Job Openings

Phasetronics, Inc. (dba Motortronics) is the leading manufacturer of SCR power controls and motor control products serving a broad range of industries.

Phasetronics, Inc. recognizes that it is our employees who make this a great place to work and we are always looking for innovative self-starter to join our team.

Openings in Magnetics for Engineers, Junior Engineers and  Board Test Technicians. Openings for Printed Circuit Board Designers I and II and Area Sales Managers.

Benefits include medical, dental, life, 401k, PDO Plan, vision and AFLAC.

For consideration, please send your resume to hr@phasetronics.com  or download and complete the job application and return to:

1600 Sunshine Drive, Clearwater, FL 33765 Attention:  Human Resources.



Phasetronics, Inc. is a drug-free workplace and an EOE.



Download Employment Application Form (PDF, 87 KB)


Mar 1st 2016: New MVC MLink 2016 Edition Now Available

MVC Programming, Startup and Diagnostics software for Windows.

Download
  • System Requirements
  • Computer with Intel® Core i3 or equivalent processor.
    Microsoft® Windows® 7 or higher with latest service pack.
    2GB or more recommended.
    Minimum screen resolution of 1024 x 768 (1280 x 800 recommended).
    100 MB of available disk space.
    Mouse or other pointing device.
    Inkjet or laser printer for printing of reports.
    E-mail with Messaging Application Programming Interface (MAPI) to e-mail reports.
    Internet Connection to download software updates.
    Ethernet or serial port.
  • Installation Instructions:
  • Unzip file to a temporary folder then run setup.exe




Feb 12th 2016: Motortronics Receives UL Approval for MVC Panel Kits

Click here to view UL Certificate


Jan 16th 2016: MLink Update Now Available for the VMX


Dec 16th 2015: MLink Update Now Available for the VMX, RX, TE-RTD12, MVC, DXT and VCM


Sep 25th 2015: MLink Update Now Available for the VMX


Sep 15th 2015: MLink Update Now Available for the MVC4


Aug 13th 2015: MLink Update Now Available for the VMX


May 13th 2015:

Motortronics launches brand new software commissioning tools for their MVC, DXT, VMX, RX and TE-RTD12 product series.

What's New in version 2.0.0.0:

- New user interface and navigation
- New setup wizard
- New Monitor panel
- New parameter search function
- New modified parameter function
- New parameter compare function
- Improved communications
- Updated help file

  • System Requirements
  • Computer with Intel® Core i3 or equivalent processor.
    Microsoft® Windows® 7 or higher with latest service pack.
    2GB or more recommended.
    Minimum screen resolution of 1024 x 768 (1280 x 800 recommended).
    100 MB of available disk space.
    Mouse or other pointing device.
    Inkjet or laser printer for printing of reports.
    E-mail with Messaging Application Programming Interface (MAPI) to e-mail reports.
    Internet Connection to download software updates.
    Ethernet or serial port.

Apr 15th 2015: RX MLink Software Update Now Available:

Version 1.4.2.4:

- Support added for firmware version 1.73 and 1.74
- Updated brochure
- Minor improvements

Download

Click here for more information on the Motortronics RX documents




Apr 2nd 2015: CT and VT TTL Catalog Now Available

Click here for the new TTL Current and Voltage Transformer Catalog


Jan 19th 2015: RX Brochure Updated Now Available:

RX Motor Protection

Motor Protection Relay

Click here to open document or right mouse click to save document 2.9 MB (PDF)



Click here for more information on the Motortronics MVC documents


Jan 14th 2015: MVC ARC Resistant Brochures Now Available:

MVC-ARC

ARC Resistant MV Starter

Click here to open document or right mouse click to save document 3.03 MB (PDF)

MVC-ARC

ARC Resistant MV Starter

Click here to open document or right mouse click to save document 2.67 MB (PDF)



Click here for more information on the Motortronics MVC documents


Dec 18th 2014: VMX MLink Software Update Now Available:

Version 1.5.3.3:

- Support added for firmware version 4.36

Download

Click here for more information on the Motortronics VMX Low Voltage Compact Soft Starter


Nov 14th 2014: MVC4 User Manual Update Now Available:

Click here for MVC4 literature.


Nov 7th 2014: MVC MLink Software Update Now Available:

Version 1.5.2.2:

- Support added for firmware version 7.34/DS1
- Communication improvements

Download

Click here for more information on the Motortronics MVC documents


Oct 16th 2014: VMX User Manual Update Now Available:

Click here for VMX literature.


Sep 8th 2014: RX MLink Software Update Now Available:

Version 1.4.2.3:

- Updated documentation
- Minor improvements

Download

Click here for more information on the Motortronics RX documents


Sep 3rd 2014: Updated Literature

- Updated: MVC user manual Spanish (Click here to go to literature page)
- New: RX user manual Spanish (Click here to go to literature page)


Aug 13th 2014: MV Contactor New and Updated Brochures Now Available

Click here to view all brochures



MVF Series MV Contactor

7.2kV - 400A

Medium Voltage Contactors

Click here to open document or right mouse click to save document 1.4 MB (PDF)

MVF Series MV Contactor

7.2kV - 630A/800A

Medium Voltage Contactors

Click here to open document or right mouse click to save document 973 KB (PDF)

MVF Series MV Contactor

12kV - 400A/630A/800A

Medium Voltage Contactors

Click here to open document or right mouse click to save document 960 KB (PDF)





Click here to view all MV Contactors


Jul 24th 2014: MMTS Motor Test Stand Series

Introducing the new MMTS Motor Test Stand Series.





Indicators

Power on Light Start Light
Running Light
Trip Light
Start Warning Buzzer
Start Light
Pendant Light
X-Line Light

MMTS Brochure

Click here to open document or right mouse click to save document 740 KB (PDF)

Click here to view MMTS documentation and software

Controls

Soft Start / Across the Line Selector Switch
Local / Off / Pendant Selector Switch
Emergency Stop Button
Start / Stop Push buttons (Local & Pendant)

Communication

Ethernet Modbus TCP
USB Port for Commisioning (MLink)

Standard Features

Phase Current Imbalance/Loss Protection
Electronic Shear Pin Protection
RTD Inputs (Optional)
Event History (60)
Starts-per-Hour Lockout Timer
Dual Ramp Settings
Kick Start Function
Jog Function

Metering Functions

% Motor Load
Current Data
“Start Current Trending” *
RTD Thermal Data (Option)
Voltage Metering
Software for Recording
Motor Data (emailable)


Jul 22nd 2014: TE-RTD12 MLink Updated.

Version 1.1.2.3

- Support added for firmware V1.46
- Updated brochure


Download


Jul 22nd 2014: Updated Brochures Now Available for the MVC4, VMX, VMX-H, VMX-S, RX, RX Green, TE-RTD12, MWH, ABC and VT MV.

Click here to view all brochures

MVC4

Medium Voltage Starter

Click here to open document or right mouse click to save document 2.27 MB

VMX Compact Starter



Click here to open document or right mouse click to save document 2.35 MB (PDF)

VMX-H "Heavy Duty"

Configured Soft Starter

Click here to open document or right mouse click to save document 896 KB (PDF)

VMX-S "Standard Duty"

Configured Soft Starter

Click here to open document or right mouse click to save document 948 KB (PDF)

RX Motor Protection

Motor Protection Relay

Click here to open document or right mouse click to save document 2.83 MB (PDF)



RX Motor Protection

Green Energy Management

Click here to open document or right mouse click to save document 688 KB (PDF)

MWH Series

Motor Winding Heater

Click here to open document or right mouse click to save document 1.02 MB (PDF)

ABC Series

Electric Motor Brake

Click here to open document or right mouse click to save document 1.35 MB (PDF)

TE-RTD12

Motor RTD Relay

Click here to open document or right mouse click to save document 772 KB (PDF)

Medium Voltage - 5kV

Med. Voltage Transformers

Click here to open document or right mouse click to save document 620 KB (PDF)




Jul 1st 2014: MVC4 Updated User Manual Now Available for 1.0 - 7.2kV and 10 - 13.8kV Editions

User Manual MVC4 Series 1.0 ~ 7.2kV - Rev 6.20

Click here to open document or right mouse click to save document 2.3 MB (PDF)

User Manual MVC4 Series 10 ~ 13.8kV - Rev 6.20

Click here to open document or right mouse click to save document 2.3 MB (PDF)

Click here to view all MVC4 documents



Jun 19th 2014: MVC MLink Software Update Now Available:

Version 1.5.1.0:

- Support added for firmware v7.30/DS1
- Motor 2 FLA range now calculated based on Service Factor
- Updated documentation
- Minor improvements

Download


Jun 2nd 2014: MVC Series Firmware updated to V7.30

The MVC series firmware has been updated to enhance the features and performance of the MVC series.

Download Firmware Revision Document (PDF, 74.7 KB)


Apr 25th 2014: MVC MLink Software Update Now Available:

Version 1.5.0.0:

- Communication baud rate increased to 115.2KB
- Updated user interface MVC MLink
- Minor improvements
- Updated help file

Download


Apr 21st 2014: New Medium Voltage Contactor Section

Available MV Contactors:

- 7.2kV, 400A (Non-Latching and Latching), 630A (Non-Latching) and 800A (Non-Latching)

- 12kV: 400A (Non-Latching), 630A (Non-Latching) and 800A (Non-Latching)

Click here for more information on the Motortronics Medium Voltage Contactors


Apr 21st 2014: DXT MLink Software Update Now Available:

Version 1.3.3.3:

- Updated e-mail client
- Minor improvements

Download

Click here for more information on the Motortronics DXT documents


Apr 16th 2014: VMX MLink Software Update Now Available:

Version 1.5.3.2:

- Updated e-mail client
- Minor improvements

Download

Click here for more information on the Motortronics VMX Low Voltage Compact Soft Starter


Apr 15th 2014: RX MLink Software Update Now Available:

Version 1.4.2.2:

- Updated e-mail client
- Minor improvements

Download

Click here for more information on the Motortronics RX documents


Apr 7th 2014: TE-RTD12 User Manual and TE-RTD12 MLink Update Now Available:

Version 1.1.2.2:

- Updated e-mail client / export engine
- Updated manual / Minor improvements

Download

Click here for more information on the Motortronics TE-RTD12 documents


Mar 18th 2014: MVF Series MV Vacuum Contactor:

- Updated user manual

- Updated brochure

Click here for more information on the Motortronics MVF documents


Feb 21st 2014: DXT MLink Software Update Now Available:

Version 1.3.3.2:

- Updated default values SP13

Download

Click here for more information on the Motortronics DXT documents


Feb 21st 2014: VCM MLink Software Update Now Available:

Version 1.8.2.1:

- Minor updates and bug fixes

Download

Click here for more information on the Motortronics VCM AC Drive


Feb 11th 2014: VCM MLink Software Update Now Available:

Version 1.8.2.0:

- Support added for firmware version 1.5
- Updated help file
- Updated user manual

Download

Click here for more information on the Motortronics VCM AC Drive


Feb 10th 2014: VCM Updated User Manual

Click here for VCM AC Drive documentation.


Jan 20th 2014: DXT MLink Software Update Now Available:

Version 1.3.3.0:

- Updated export engine
- Updated E-mail engine (Mobile device view compatible)
- Exported PDFs Windows 8 / 8.1 and MAC OS X integrated Viewer compatible
- Minor improvements

Download

Click here for more information on the Motortronics DXT documents


Jan 15th 2014: RX MLink Software Update Now Available:

Version 1.4.2.0:

- Updated export engine
- Updated E-mail engine (Mobile device view compatible)
- Exported PDFs Windows 8 / 8.1 and MAC OS X integrated Viewer compatible
- Minor improvements

Download

Click here for more information on the Motortronics RX documents


Jan 14th 2014: TE-RTD12 MLink Software Update Now Available:

Version 1.1.2.0:

- Updated export engine
- Updated E-mail engine (Mobile device view compatible)
- Exported PDFs Windows 8 / 8.1 and MAC OS X integrated Viewer compatible
- Minor improvements

Download

Click here for more information on the Motortronics TE-RTD12 documents


Jan 13th 2014: VMX MLink Software Update Now Available:

Version 1.5.3.0:

- Updated export engine
- Updated E-mail engine (Mobile device view compatible)
- Exported PDFs Windows 8 / 8.1 and MAC OS X integrated Viewer compatible
- Minor improvements
- Updated documentation

Download

Click here for more information on the Motortronics VMX Low Voltage Compact Soft Starter


Jan 10th 2014: VCM MLink Software Update Now Available:

Version 1.8.1.0:

- Updated export engine
- Updated E-mail engine (Mobile device view compatible)
- Exported PDFs Windows 8 / 8.1 and MAC OS X integrated Viewer compatible
- Minor improvements

Download

Click here for more information on the Motortronics VCM AC Drive


Jan 2nd 2014: MVC Plus MLink Software Update Now Available:

Version 1.4.3.0:

- Added Motor Speed (RPM) - Tachometer
- Improvements e-mail client and reporting

Download


Dec 10th 2013: MT Series published pricing

All published pricing for the MT Drives and Accessories has been suspended until further notice.

Click here for news release (PDF 135 KB).

For MT Series AC drive pricing please contact us.


Dec 5th 2013: MVC Plus MLink Software Update Now Available:

Version 1.4.2.0:

- Upgraded report export and e-mail engine
- Minor improvements and bug fixes

Download


Dec 3rd 2013: MVC Series Firmware updated to V7.26

The MVC series firmware has been updated to enhance the features and performance of the MVC series.

Download Firmware Revision Document (PDF, 73.3 KB)


Nov 8th 2013: VMX Compact Soft Starter now with 65KA Short Circuit Rating Standard

We are pleased to announce that the VMX Compact Soft Starter now has a short circuit rating of 65KA without semi-conductor fuses.

About the VMX Compact Soft Starter.

AC Supply Voltage: 200 - 600 Vac

HP Ratings: 3 to 1200 HP

Amp Ratings: 18 to 1250 Amps

Overload Rating: 500% for 60 sec.

Enclosure: Available as Module Only or in NEMA 1/12

Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.

More information




Nov 8th 2013: Updated VMX / VMX Configured Documentation

Specification sheets

- VMX Specification Sheet (PDF) (Download)
- VMX Configured Specification Sheet (PDF) (Download)
- VMX Configured with Deadfront Specification Sheet (PDF) (Download)

Manuals

- VMX User Manual (PDF) (Download)
- VMX Basic Installation and Quick Startup Guide (PDF) (Download)


Oct 30th 2013: MVC Plus MLink Software Update Now Available:

Oct 30th 2013: Version 1.4.1.0:

- New diagnostics panel: RTD 1 - 12 Readout in °C and °F
- Updated diagnostics report
- Updated help file
- Minor improvements and bug fixes

MVC Plus MLink

Download


Oct 2nd 2013: MLink Software Updates Now Available:

- Updated trender playback function
- Small improvements

VCM MLink

Download

RX MLink

Download

TE-RTD12 MLink

Download


Sep 26th 2013: DXT MLink Software Update Now Available:

Version 1.3.2.0:

- Trender signals added Power Factor Sign and Power Factor
- Updated trender playback function
- Minor improvements and bug fixes

Download


Sep 20th 2013: MVC Plus MLink Software Update Now Available:

- Trender signals added Power Factor Sign and Power Factor

MVC Plus MLink

Download


Sep 13th 2013: VMX MLink Software Update Now Available (V1.5.2.0):

- Updated trender playback function
- Minor improvements

VMX MLink

Download


Aug 30th 2013: MVC Plus MLink Software Update Now Available:

- Updated trend playback function

MVC Plus MLink

Download


Aug 28th 2013: New Phase Controller Product Section

Click here to view Phase Controller Products


Aug 12th 2013: Update DXT Specification and New ME2 Ratings and Dimensions Data Sheet

Click here to view all DXT Series documents

Click here to view all ME2 Series documents


Jul 8th 2013: MVC Plus MLink Software Update Now Available:

- Support added for firmware version 7.26

MVC Plus MLink

Download


Jun 14th 2013: Updated RX User Manual Now Available

Click here to view all RX Series documents


Jun 10th 2013: New Mobile Web-Apps Available for MVC Plus, VMX, DXT, TE-RTD12 and RX

We are pleased to announce the availability of our new series of mobile web-apps for:

MVC Plus Series: Medium Voltage Soft Starter

VMX Series: Low Voltage Soft Starter

DXT Series: Advanced Digital Soft Starter

TE-RTD12: Motor RTD Monitor / Relay Device

RX: Motor Protection Relay

The Web-App runs on iPhone, iPad, iPod, Android, Kindle, Windows Mobile.

Mobile App Benefits:

- Quick parameter / function / set-point with built-in search function

- Wiring / connection diagrams

- Documentation Access

Web-App Features:

MVC Plus Series: Set-point Pages Overview with storage, basic setup wizard and documentation

VMX Series: Function Pages Overview with storage, Ratings Overview, Basic Setup Wizard, Connection Diagrams and Documentation

DXT Series: Set-point Pages Overview with storage, Basic Setup Wizard and Documentation

TE-RTD12: Function Pages Overview with storage, Basic Setup Wizard, Connection Diagrams and Documentation

RX: Function Pages Overview with storage, Basic Setup Wizard, Connection Diagrams and Documentationon

To use the new web-apps simply go to Motortronics.com from your mobile device and click on the "Mobile Apps" button.


May 8th 2013: VCM MLink Software Update Now Available:

May 8th 2013: Version 1.8.0.0:

- Upgraded PDF Engine
- Upgraded monitor panel
- Minor improvements and bug fixes

Download

Click here for more information on the Motortronics VCM AC Drive


Apr 23rd: Updated RX Specifications Sheet

Click here to view all RX Series documents


Apr 19th: Updated DXT Specifications Sheet

Click here to view all DXT Series documents


Apr 17th: Updated VMX Specifications and Dimension Sheet

Click here to view all VMX Series documents


Apr 16th 2013: MVC Plus MLink Software Update Now Available:

- Support added for firmware version 6.88

MVC Plus MLink

Download


Apr 9th 2013:VMX Quick Start Flyer:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

Click here to open document or right mouse click to save document 189 KB (PDF)

Click here to view all VMX documents


MVC Plus Updated User Manual Now Available for 2.3 - 7.2kV and 10 - 13.8kV Editions

User Manual MVC Plus Series 2.3 ~ 7.2kV - Rev 6.14

Click here to open document or right mouse click to save document 1.8 MB (PDF)

User Manual MVC Plus Series 10 ~ 13.8kV - Rev 6.14

Click here to open document or right mouse click to save document 1.8 MB (PDF)

Click here to view all MVC Plus documents


Mar 7th 2013: DXT MLink Software Update Now Available:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

DXT MLink

Download


Mar 5th 2013: TE-RTD12 MLink Software Update Now Available:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

TE-RTD12 MLink

Download

Mar 5th 2012: TE-RTD12 Updated User Manual Now Available

User Manual

TE-RTD12

Click here to open document or right mouse click to save document 1.6 MB (PDF)


Click here to view all TE-RTD12 documents

Feb 15th 2013: VMX MLink Software Update Now Available:

- Support added for firmware version 4.35

VMX MLink

Download


Feb 5th 2013: RX MLink Software Update Now Available:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

RX MLink

Download

Jan 21st 2013: VMX MLink Software Update Now Available:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

VMX MLink

Download


Jan 18th 2013: MVC Plus MLink Software Update Now Available:

- New PDF Engine icludes support for Windows 8® PDF View and MAC OS X PDF Viewer
- Update monitor panel
- Upgraded installer
- Many small improvements

MVC Plus MLink

Download


Dec 19th 2012

Updated MWH Installation and Startup Manual Now Available

The Motortronics MWH Series Solid State Motor Winding Heater is designed to prevent condensation build-up by applying a low level current to the AC motor windings when the motor is in the “off” condition. Motor windings are susceptible to condensation formation each time the motor is stopped and the windings’ temperature drops below the dew point. Over a period of time this condensation build- up can degrade the insulation of the windings and cause a short circuit when the motor is started. The same problem can occur when motors are not operated for an extended period of time. This is especially true for damp and humid locations.



MWH Series Manual

Click here to open document or right mouse click to save document 1.05 MB (PDF)

More Information on MWH Series Winding Heater


Dec 13th 2012

NEW MVF SERIES MEDIUM VOLTAGE VACUUM CONTACTOR NOW AVAILABLE

Motortronics 7.2kV Class, ‘Non-Latching’ and ‘Latching’ Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 7.2 kV and can be used for continuous AC operating currents of up to 400 amperes. Control voltage for the contactor is AC/DC 100~125V or AC/DC 200~230V, including an auxiliary relay with 3 NO and 2 NC contacts.



MVF Series MV Contactors

Medium Voltage Contactors

Click here to open document or right mouse click to save document 1.47 MB (PDF)

More Information on MVF Series Contactors


Dec 13th 2012

The new MVC4 Medium Voltage Soft Starter is now available.

MVC4

Medium Voltage Starter

NEW

Click here to open document or right mouse click to save document 3.27 MB


Dec 12th 2012

The following Updated brochures are now available:

Configured Soft Starters

VMX-S with Shunt Rated Bypass

UPDATED

Click here to open document or right mouse click to save document 1.39 MB (PDF)

VMX-H with Line Start Rated Bypass

UPDATED

Click here to open document or right mouse click to save document 1.3 MB (PDF)


Nov 13th 2012: Update ABC Series Installation / Operation Manual and Ratings and Dimensions Sheet.

Installation & Operation Manual

Click here to open document or right mouse click to save document 1.21 MB (PDF)

Ratings & Dimensions Sheet

Click here to open document or right mouse click to save document 438 KB (PDF)

Click here to view all ABC Series documents


Oct 26th 2012: MLink Software Updates Now Available:

- Upgraded for Windows 8® support
- Updated documentation
- Upgraded installer
- Many small improvements

VCM MLink

Download

MVC Plus MLink

Download

VMX MLink

Download

RX MLink

Download

DXT MLink

Download

TE-RTD12 MLink

Download


Sep 18th: Updated TE-RTD12 User Manual.

Click here to view all TE-RTD12 Series documents


Sep 13th: Updated RX User Manual.

Click here to view all RX Series documents


Sep 7th 2012: Updated ABC Specification, Dimensions and Ratings Sheet.

Click here to view all ABC Series documents


Sep 7th 2012: Updated TE-RTD12 MLink Software Update Now Available:

TE-RTD12 MLink 2012: Version 1.04.0:

Sep 7th 2012: Version 1.0.4.0:

- Support added for firmware 1.42 and 1.43
- Many small improvements

Download


Aug 30th 2012: Update ABC Series Installation and Operation Manual

Installation & Operation Manual

Click here to open document or right mouse click to save document 1.22 MB (PDF)

Click here to view all ABC Series documents


Aug 15th 2012: DXT Updated Installation and Operations Manual Now Available

Installation and Operations Manual DXT Series

Click here to open document or right mouse click to save document 1.85 MB (PDF)

Click here to view all DXT series documents


Aug 10th 2012: MVC Plus Updated User Manual Now Available for 2.3 - 7.2kV and 10 - 13.8kV Editions

User Manual MVC Plus Series 2.3 ~ 7.2kV - Rev 6.09

Click here to open document or right mouse click to save document 1.72 MB (PDF)

User Manual MVC Plus Series 10 ~ 13.8kV - Rev 6.09

Click here to open document or right mouse click to save document 1.72 MB (PDF)

Click here to view all MVC Plus documents


Jul 12th 2012: MVC Plus Updated User Manual Now Available for 2.3 - 7.2kV and 10 - 13.8kV Editions

Click here to view all MVC Plus documents


Jun 15th 2012: Motortronics Mobile Website Launched:

We are pleased to anounce that motortronics.com is now available in a mobile version. To view enter motortronics.com into the browser of your mobile device and the website will automatically switch to the mobile version for small screen devices.

To view our mobile site on your desktop go to : www.motortronics.com/mobile


Jun 12th 2012: MLink Software Update Now Available:

- Update trend-recorder function

VCM MLink

Download

MVC Plus MLink

Download

VMX MLink

Download

RX MLink

Download

DXT MLInk

Download

TE-RTD12 MLink

Download


Jun 7th 2012: VMX MLink Software Update Now Available:

Jun 7th 2012: Version 1.4.2.3:

- Minor improvements and fixes
- Support added for firmware 4.32
- Support added for firmware 4.31

Download


Jun 1st 2012: Updated TE-RTD12 MLink Software Update Now Available:

Jun 1st 2012: Version 1.0.3.0:

- Support added for firmware 1.37, 1.40 and 1.41
- Updated TE-RTD12 graphics
- Updated help file
- Updated TE-RTD12 Manual and Brochure
- Small improvements

Download


Jun 1st 2012: VMX Basic Installation and Quick Startup Guide

Updated VMX Basic Installation and Quick Startup Guide now available.

VMX Quick Startup Guide

Click here to open document or right mouse click to save document 2.06 MB (PDF)






May 24th 2012: TE-RTD12 User Manual and brochure update Now Available

User Manual

TE-RTD12

Click here to open document or right mouse click to save document 1.58 MB (PDF)

Brochure

TE-RTD12

Click here to open document or right mouse click to save document 885 KB (PDF)



Click here to view all TE-RTD12 documents


May 21st 2012: VCM MLink Software Update Now Available:

May 21st 2012: Version 1.6.1.0:

- New: Automatic scaling function for trender
- New: Cursor measurement values trend report
- New: Open trend files from file menu
- Many small improvements

Download

Click here for more information on the Motortronics VCM AC Drive


May 21st 2012: RX MLink Software Update Now Available:

May 21st 2012: Version 1.3.1.0:

- New: Automatic scaling function for trender
- New: Cursor measurement values trend report
- New: Open trend files from file menu
- Many small improvements
- Upgrade communication engine
- Support added for firmware version 1.72

Download


May 21st 2012: DXT MLink Software Update Now Available:

May 21st 2012: Version 1.2.2.0:

- New: Automatic scaling function for trender
- New: Cursor measurement values trend report
- New: Open trend files from file menu
- Many small improvements
- Upgrade communication engine

Download


May 21st 2012: MVC Plus MLink Software Update Now Available:

May 21st 2012: Version 1.3.2.2:

- Many small improvements
- Upgraded communication engine

Download


May 21st 2012: VMX MLink Software Update Now Available:

May 21st 2012: Version 1.4.2.0:

- New: Automatic scaling function for trender
- New: Cursor measurement values trend report
- New: Open trend files from file menu
- Many small improvements
- Upgrade communication engine


Download


May 21st 2012: Updated TE-RTD12 MLink Software Update Now Available:

TE-RTD12 Mlink 2012: Version 1.01.0:

Apr 12th 2012: Version 1.0.1.0:

- Updated trender zoom function
- Updated status readout
- Updated event history readout
- Many small improvements

Download


Mar 28th 2012: RX MLink 2012 Edition Now Available:

Mar 28th 2012: Version 1.3.0.1:

- Support added for firmware versions 1.69 and 1.70
- Trender: updated
- Minor improvements and changes

Download


May 17th 2012

The following Updated brochures are now available:

Configured Soft Starters

VMX-S with Shunt Rated Bypass

Heavy Duty Configured Soft Starter

UPDATED

Click here to open document or right mouse click to save document 1.85 MB (PDF)

VMX-H with Line Start Rated Bypass

Extreme Duty Configured Soft Starter

UPDATED

Click here to open document or right mouse click to save document 1.56 MB (PDF)


May 11th 2012: MVC Plus MLink Software Update Now Available:

May 11th 2012: Version 1.3.2.0:

- New: Automatic scaling function for trender
- New: Cursor measurement values trend report
- New: Open trend files from file menu
- Many small improvements

Download


Apr 27th 2012: MVC Plus Updated User Manual Now Available for 2.3 - 7.2kV and 10 - 13.8kV Editions

User Manual MVC Plus Series 2.3 ~ 7.2kV - Rev 6.06

Click here to open document or right mouse click to save document 1.72 MB (PDF)

User Manual MVC Plus Series 10 ~ 13.8kV - Rev 6.06

Click here to open document or right mouse click to save document 1.72 MB (PDF)

Click here to view all MVC Plus documents


Apr 23rd 2012: VCM Sensorless Vector AC Drive MLink Software Update Now Available:

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector AC Drive.

Apr 23rd 2012: Version 1.6.0.1:

- Support added for firmware v1.4
- Minor improvements and changes

Download

Click here for more information on the Motortronics VCM AC Drive


Apr 23rd 2012: RX MLink Software Update Now Available:

Apr 23rd 2012: Version 1.3.0.2:

- Minor improvements and changes
- Updated help file

Download


Apr 18th 2012: DXT MLink Software Update Now Available:

DXT MLink 2012: Version 1.2.1.0:

- Support added for V7.21
- Updated trender zoom function
- Updated status readout
- Updated event history readout
- Many small improvements

Download


Apr 15th 2012: MVC Plus MLink Software Update Now Available:

MVC Plus MLink 2012: Version 1.3.1.1:

- Many small improvements

Download


Apr 13th 2012: VMX MLink Software Update Now Available:

VMX MLink 2012: Version 1.4.1.0:

- Updated trender zoom function
- Updated status readout
- Many small improvements
- Updated user manual and Quick Startup
- Updated help file

Download


Apr 12th 2012: Updated TE-RTD12 MLink Software Update Now Available:

TE-RTD12 Mlink 2012: Version 1.01.0:

Apr 12th 2012: Version 1.0.1.0:

- Updated trender zoom function
- Updated status readout
- Updated event history readout
- Many small improvements

Download


Mar 28th 2012: RX MLink 2012 Edition Now Available:

Mar 28th 2012: Version 1.3.0.1:

- Support added for firmware versions 1.69 and 1.70
- Trender: updated
- Minor improvements and changes

Download


Mar 23th 2012: Updated VMX Compact Soft Starter User Manual

VMX Series Compact Soft Starter (200 ~ 600V, 18 - 1250A):



User Manual

VMX Series

Click here to open document or right mouse click to save document 3.14 MB (PDF)

Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.


Mar 19th 2012: VCM Sensorless Vector AC Drive MLink 2012 Update Now Available

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector AC Drive.

Mar 19th 2012: Version 1.6.0.0:

- 2012 Release: New Platform
- New Status Panel / Upgraded Monitor Panel (4 Gauges w/ PID tuner)
- New Trend-recorder signal measurement function (min, max, avg, and peak-peak)
- Updated graphics
- Improved communication
- Trender: updated cursor management
- Trender: function to switch between % and actual values
- Trender: Minimize function
- Updated documentation
- Updated help file

Download

Click here for more information on the Motortronics VCM AC Drive

VCM MLink Screenshots




Mar 15th 2012: VMX Quick Start Guide

Updated VMX Basic Installation and Quick Startup Guide now available.

VMX Quick Startup Guide

Click here to open document or right mouse click to save document 1.5 MB (PDF)




Mar 14th 2012: MVC Plus MLink Update:

MVC Plus MLink 2012: Version 1.3.1.0:

- Updated trender zoom function
- Updated status readout
- Updated event history readout
- Many small improvements

Download


Feb 27th 2012: Marine Certified Products Brochure Now Available:

Marine Products

Click here to open document or right mouse click to save document 976 KB (PDF)


Feb 17th 2012: DXT MLink 2012 Edition Now Available:

DXT MLink 2012: Version 1.2.0.0:

- Region support added
- 2012 Release: New Platform
- Updated graphics
- Improved communication
- Trender: updated cursor management
- Trender: function to switch between % and actual values
- Trender: Minimize function
- Updated help file

Download


Feb 17th 2012: VMX MLink and TE-RTD12 2012 Edition Update Now Available:

TE-RTD12 MLink 2012: Version 1.0.0.1:

- Regional support added
- Many small improvements

Download

VMX MLink 2012: Version 1.4.0.1:

- Regional support added
- Many small improvements

Download


Feb 14th 2012: RX MLink 2012 Edition Now Available:

RX MLink 2012: Version 1.3.0.0:

- Region support added
- 2012 Release: New Platform
- Updated graphics
- Improved communication
- Trender: updated cursor management
- Trender: function to switch between % and actual values
- Trender: Minimize function
- Updated help file

Download


Feb 7th 2012: MVC Plus MLink Update:

MVC Plus MLink 2012: Version 1.3.0.1:

- Region Support Added

Download


Feb 1st 2012: ABC Series Installation and Operation Manual

Installation & Operation Manual

Click here to open document or right mouse click to save document 1.22 MB (PDF)

Click here to view all ABC Series documents




Jan 25th 2012: VMX MLink 2012 Edition Now Available:

VMX MLink 2012: Version 1.4.0.0:

- Updated GUI
- Improved communication
- Trender: updated cursor management
- Trender: function to switch between % and actual values
- Trender: Minimize function added
- Updated help file / user manual

Download


Jan 18th 2012: New TE-RTD12 USer Manual and MLink 2012 Edition Now Available:

TE-RTD12 Mlink 2012: Version 1.0.0.0:

The TE-RTD12 Series MLink software allows users to program, monitor and diagnose the TE-RTD12 Motor RTD Relay

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet Application Setup Wizard

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 4 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering, playback and signal measuring mode (Avg, Min, Max, Peak).

Bullet Status and Diagnostics Panel for quick status and fault history overview

Bullet Event History and Log

Bullet Communication connection for serial, USB and Ethernet (Modbus/TCP)

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates

Download

TE-RTD12 User Manual Now Available

User Manual

TE-RTD12

Click here to open document or right mouse click to save document 1.4 MB (PDF)

Click here to view all TE-RTD12 documents




Jan 17th 2012: MVC Plus MLink 2012 Edition Now Available:

MVC Plus MLink 2012: Version 1.3.0.0:

- Updated GUI
- Improved MVC Plus communication
- Trender: updated cursor management
- Trender: function to switch between % and actual values
- Trender: Minimize function added
- Warranty form added export to rtf format

Download


Jan 5th 2012: MVC Plus Updated User Manual Now Available

User Manual

User Manual MVC Plus Series 2.3 ~ 7.2kV

Click here to open document or right mouse click to save document 1.72 MB (PDF)

User Manual MVC Plus Series 10 ~ 13.8kV

Click here to open document or right mouse click to save document 1.72 MB (PDF)

Click here to view all MVC Plus documents


Dec 5th 2011: MVC Plus Updated User Manual Now Available

User Manual MVC Plus Series

Click here to open document or right mouse click to save document 1.65 MB (PDF)

Click here to view all MVC Plus documents


Dec 2nd 2011: MVC Plus Updated Specifiation and Dimension Sheet Now Available

Click here to view documents


Nov 30th 2011: Software updated for DXT MLink now available

DXT MLink:

Nov 23rd 2011: Version 1.1.1.3:

- Updated trender - zoom / cursor function

File: Zip File

Download

MVC Plus MLink:

Nov 30th 2011: Version 1.2.1.4:

- Updated trender - zoom / cursor function

Download

VMX Version MLink

Nov 30th 2011: Version 1.3.1.2:

- Updated trender - zoom / cursor function

Download

RX: Version 1.2.1.0 Changes:

Nov 30th 2011: Version 1.2.1.2:

- Updated trender - zoom / cursor function

- Updated brochure

Download


Nov 27th 2011

The following New and Updated brochures are now available:

Soft Starters, Motor Protection and Heater Controllers

VMX-H "Heavy Duty"

Configured Soft Starter

UPDATED

Click here to open document or right mouse click to save document 1.28 MB (PDF)

RX Motor Protection

Motor Protection Relay

UPDATED

Click here to open document or right mouse click to save document 1.92 MB (PDF)

MWH Series

Motor Winding Heater

UPDATED

Click here to open document or right mouse click to save document 862 KB (PDF)



AC Drives / Heater Controllers

MT Series

AC Drive

UPDATED

Click here to open document or right mouse click to save document 3.15 MB

VCM Series

AC Drive

UPDATED

Click here to open document or right mouse click to save document 2.77 MB (PDF)

ME2 Series

AC Drive

UPDATED

Click here to open document or right mouse click to save document 1.24 MB (PDF)



600V Current Transformers Ansi / Non-Ansi Rated Window Type, Contactors



CT 600V Non-Ansi Rated

Window Type

Current Transformers

UPDATED

Click here to open document or right mouse click to save document 545 KB (PDF)

CT 600V Ansi Rated

Window Type

Current Transformers

UPDATED

Click here to open document or right mouse click to save document 678 KB (PDF)

7.2kV Contactor



Medium Voltage Contactors

UPDATED

Click here to open document or right mouse click to save document 1.47 MB (PDF)





Click here to view all available sales literature.


Nov 23rd 2011: Software updated for DXT MLink now available

DXT MLink:

Nov 23rd 2011: Version 1.1.1.2:

- Updated status / event report Ground Fault Current Scaling

File: Zip File

Download

MVC Plus MLink:

Nov 23rd 2011: Version 1.2.1.3:

- Updated status / event report Ground Fault Current Scaling

Download


Nov 3rd

Introducing the New TE-RTD12 Motor RTD Relay



Click here for more information



12 built-in RTD Inputs

2 Isolated Digital Inputs (4-20mA)

3 Programmable Form-C Output Relays

2 Isolated Analog Inputs (4-20mA)

Differential Current Feedback Monitoring

RS485 MODBUS-RTU Communication


The TE-RTD12 Relay device adds advanced RTD (Resistor Temperature Detector) and differential current monitoring capability to your new or existing motor system. The TE-RTD12 Relay device offers 12 built-in RTD inputs, 3 programmable output relays (5A), 2 isolated analog inputs (4-20mA), 1 isolated analog output (4-20mA), 3 isolated digital inputs, and differential current feedback monitoring.

Additionally, an RS485 (2 wire) communication port is available for use with a master device (PLC / SCADA / Operator Interface) for the purpose of programming and/or monitoring.

Programmable relay outputs are provided that can be configured for a system function or for use as a global Alarm or Trip based on temperature readout, which can be entered in ºC or ºF.
A built-in event recorder stores fault history of past events with data points including Alarm / Trip Code, Current / Temperature value, Analog input value and Date / Time Stamp.

The TE-RTD12 Relay device can be mounted on a back panel using the mounting bracket or DIN-Rail mount.

Click here for more information or contact us.




Apr 22nd 2010

New Medium Voltage Control Power Transformers are now available for input voltages ranging from 7.2 to 15kV

We are pleased to announce that the new Models PTG5-1-110 & PTG5-2-110 and Models PTW5-1-110 & PTW5-2-110 Control Power Transformers.

Click here for more information







Medium Voltage Transformers Brochure

5kV, 7.2kV and 15kV Class

Click here to open document or right mouse click to save document 1.02 MB (PDF)


Apr 19th 2010

MVC Plus MLink Software Update

An update is now available for the MVC Plus Link Software. This update adds long-term trending funtion to the software.

File: Zip File (21.4 MB)

Download


Apr 9th 2010

MOTORTRONICS INTRODUCES NEW MEDIUM VOLTAGE CONTACTORS FOR 7.2 and 12 kV

Medium Voltage Contactor - 7.2 kV Class

Motortronics 7.2kV Class, ‘Non-Latching’ (C) and ‘Latching’ (CJ) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 7.2 kV and can be used for continuous AC operating currents of up to 400, 630 or 800 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models CJ).

Datasheet 7.2kV Contactor (PDF 237 kB)

Non-Latching (C) - uses constant-on electromagnetic coils to close, and hold closed the vacuum bottle contacts. When the power to the electromagnetic coil is removed, the vacuum chamber contacts spring open (termed as; electrically held contacts or non-latching contacts).

Latching (CJ) - uses separate coils and mechanisms to both close and open the vacuum bottle contacts (termed as; mechanically held or latching, contacts).

RATED
CURRENT

RATED
VOLTAGE

PART NUMBER
NON-LATCHING (C)

PART NUMBER
LATCHING (CJ)

400A

7.2kV

34-400-3-7200C

34-400-7200-CJ

630A

7.2kV

34-630-3-7200C

34-630-7200-CJ

800A

7.2kV

34-800-3-7200C

34-800-7200-CJ




Medium Voltage Contactor - 12 kV Class

Motortronics 12kV Class, ‘Non-Latching’ and ‘Latching’ (L) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 12 kV and can be used for continuous AC operating currents of up to 400 or 630 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models L).

Datasheet 12kV Contactor (PDF 216 kB)

Non-Latching - uses constant-on electromagnetic coils to close, and hold closed the vacuum bottle contacts. When the power to the electromagnetic coil is removed, the vacuum chamber contacts spring open (termed as; electrically held contacts or non-latching contacts).

Latching (L) - uses separate coils and mechanisms to both close and open the vacuum bottle contacts (termed as; mechanically held or latching, contacts).

RATED
CURRENT

RATED
VOLTAGE

PART NUMBER
NON-LATCHING

PART NUMBER
LATCHING (L)

400A

12kV

34-400-3-12000

34-400-12000L

630A

12kV

34-630-3-12000

34-630-12000L

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers, Control Power Transformers and Contactors

Mar 23rd 2010

Updated Rx MLink Software Now Available

A MLink software update is now available for the Rx Motor Protection Relay, V1.03.10.

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.



Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 4.66 MB (PDF)

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.




Rx Motor Protection
Click here to open document or right mouse click to save document
User Manual

ZCT Option
Click here to open document or right mouse click to save document

Zero Sequence GF CT Option

Installation and Info Sheet


Rx Series MLink Programming Software
Click here to download file





Mar 16th 2010

New Soft Starter Application Brochures now available.

Dedicated soft starter brochures are now available for pumping, conveyor and compressor applications.

Did you know that Motortronics soft starters include dedicated application functions to handle the toughest applications?

Click here to view our low voltage soft starter products.

Click here to view our medium voltage soft starter products.

Soft Starter Dedicated Application Brochures

Soft Starters for Pumping Applications

Click here to open document or right mouse click to save document 1 MB (PDF)

Soft Starters for Compressor Applications

Click here to open document or right mouse click to save document 1.08MB (PDF)

Soft Starters for Conveyor Applications

Click here to open document or right mouse click to save document 1.12 MB (PDF)


Mar 12th 2010

Control Power Transformers 7.2kV

We are pleased to announce that the CPT3 Control Power Transformer is now recognized up to 7.2kV (Maximum Primary Voltage).

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers

Medium Voltage Transformers Brochure

5kV, 7.2kV and 15kV Class

Click here to open document or right mouse click to save document 1.02 MB (PDF)


Feb 12th 2010

VCM Sensorless Vector AC Drive MLink Software Update Now Available

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector Drive

File: Zip File (18.9 MB)

Download




Feb 4th 2010

MVC Plus MLink Software Update

A maintenance release is now available for the MVC Link Software.

File: Zip File (21.4 MB)

Download


Jan 29th 2010

MVC Link Software

A maintenance release is now available for the MVC Link Software.

File: Zip File (21.1 MB)

Download


Jan 19th 2010

RX Preventive Maintenance System accessible via your web-browser*

Our Rx Motor Protection Relay in combination with our VS1 device can be used for Motor preventive maintenance. View real-time energy data-logging, fault status and maintenance status via your web-browser.

Preventive Maintenance

Setup maintenance thresholds
E-mail motor data and maintenance information
Long-term Energy Trending
All information accessible via standard web-browser*

Monitoring

Customizable Monitor Pages with up to 20 Signals per Page
Select from Predefined System Signals
Create Custom Signals with Custom Scaling, Description and Units

Trending & Data Logging

Log up to 64 Signals with Date and Time Stamp
Configurable Sample Rate with Data Logging up to 3 Years
Export or E-Mail Trend Data
Offload Data to FTP Server

Alarm Monitoring

Define up to 64 Alarms
Alarm History Overview with Date and Time Stamp
Alarm Notification via SMS* or E-mail*



* E-mail / FTP access requires Network Connection / SMS requires GSM/GPRS Modem

RX Motor Protection

Preventive Maintenance

Click here to open document or right mouse click to save document 1.03 MB (PDF)

BulletRead More

BulletDownload Brochure (PDF, 489KB)

Click Image for information about the Motortronics 64-VS1 Module




Jan 15th 2010

Updated Rx User Manual and ZCT Option Info Sheet Now Available



Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 4.66 MB (PDF)

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.




Rx Motor Protection
Click here to open document or right mouse click to save document
User Manual

ZCT Option
Click here to open document or right mouse click to save document

Zero Sequence GF CT Option

Installation and Info Sheet


Rx Series MLink Programming Software
Click here to download file





Dec 31st 2009

A New Brochure is now available for our 600V Low Voltage Transformers.

Low Voltage - 600V

Transformers

Low Voltage Transformers

Click here to open document or right mouse click to save document 1.29 MB (PDF)



Current, Voltage and Control Power Transformers

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers

CT 600V Non-Ansi Rated

Window Type

Current Transformers

Click here to open document or right mouse click to save document 770 KB (PDF)

CT 600V Ansi Rated

Window Type

Current Transformers

Click here to open document or right mouse click to save document 888 KB (PDF)

Medium Voltage - 5kV

Transformers

Med. Voltage Transformers

Click here to open document or right mouse click to save document 1.02 MB (PDF)

.


Dec 16th 2009 : VMX Compact Soft Starter

Updated VMX User Manual Now Available

Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.



VMX Series

User Manual

Click here to open document or right mouse click to save document 2.24 MB (PDF)

VMX Compact Starter

Sales Brochure

Click here to open document or right mouse click to save document 4.65 MB (PDF)


Dec 8th 2009 : VCM Series Sensorless Vector AC Drive

New VCM User Manual Now Available

VCM Series is a compact, cost-effective drive with features typically found only in more complex and expensive AC drives. This full featured sensorless vector drive is recognized for being simple to set up, program and operate. Available in ratings from 0.5 to 75HP, the VCM Series is ideally for nearly any application. The convenient operator panel provides simple, yet informative interface during setup and operation.

The tactile feedback keypad is used for programming the drive and motor speed can be controlled using either the keypad or the handy, built-in potentiometer. The alphanumeric display indicates operation, status and fault read-out and is easily visibile in low ambient light conditions. In addition, LED indicators provide direction of rotation, operating status and drive output information. An optional two-line LCD display is available.



VCM Series AC Drive

User Manual

Click here to open document or right mouse click to save document 2.13 MB (PDF)

VCM Series

AC Drive

Click here to open document or right mouse click to save document 2.13 MB (PDF)




Nov 25th 2009

Updated MLink software versions are now available for the MVC Plus Series and VMX Series.

VMX Series MLink Software V1.02.00

File: Zip File (17.6 MB)

Download

MVC Plus Series MLink Software V1.00.07

File: Zip File (21.1 MB)

Download


Nov 3th 2009

New Brochures are now available for the Medium Voltage Transformers

Medium Voltage Transformers

Voltage Transformers

Click here to open document or right mouse click to save document 1.02 MB (PDF)



Current, Voltage and Control Power Transformers

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers.


Jul 8th 2011: Updated Rx Motor Protection User Manual

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.



User Manual

RX Motor Protection

Click here to open document or right mouse click to save document 1.62 MB (PDF)





Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.




Rx Motor Protection
Click here to open document or right mouse click to save document
User Manual

ZCT Option
Click here to open document or right mouse click to save document

Zero Sequence GF CT Option

Installation and Info Sheet


Rx Series MLink Programming Software



Download


Jul 7th 2011: VMX and RX MLink Software Update Now Available

VMX Version 1.2.0.1 Changes:

- Support added for firmware V4.09
- Improved OFFLINE project creation (Fn01)
- Many small improvements

Download

RX: Version 1.2.0.3 Changes:

- Minor Improvements for System Settings

Download


Jun 30th 2011: VMX MLink Software V1.2.0.0 with Ethernet Communication and Trender Measurement Function

This software offers users ease of programming, startup and trouble-shooting for the VMX Low-voltage soft starter

2011 VMX MLink Software

Version 1.2.0.0 Changes:

- New Ethernet communication VMX MLink can now be used over a Modbus/TCP network.
- New Trend-recorder signal measurement function (min, max, avg, and peak-peak)
- New Communication layer for faster parameter read/write
- Updated parameter reports
- Updated parameter overview
- Updated parameter management
- Updated demo modes for monitor, status and trender
- Support for firmware v4.24, 4.25 and 4.26 added
- Updated help file
- Many small improvements

VMX Ethernet Communication Trend Signal Measurement Function

Click images to enlarge



File: Zip File

Download


Jun 29th 2011: Update Rx MLink software V1.2.0.2

What's new in this update:

- Minor changes and improvements

File: Zip File

Download


May 31st 2011: VCM Sensorless Vector AC Drive MLink Software Update Now Available: V1.5.0.0

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector Drive

What's new in this update:

- New Ethernet communication, VCM MLink can now be used over a Modbus/TCP network.
- New Communication layer for faster parameter read/write
- Updated parameter reports
- Updated parameter overview
- Updated parameter management
- Updated help file

VCM MLink Software VCM Ethernet Communication

Click images to enlarge

File: Zip File

Download


Apr 21st 2011: Updated MVC Plus

May 25th 2011: Update Rx MLink software V1.2.0.1

What's new in this update:

- Support added for firmware version 1.68

File: Zip File

Download


Apr 21st 2011: Updated MVC Plus and MVX Brochure Now Available.

Now with ABS (Marine and Offshore) classification.

VMX Compact Starter

Click here to open document or right mouse click to save document 5.02 MB (PDF)

MVC Plus MV Starter

Click here to open document or right mouse click to save document 2.64 MB




Apr 8th 2011: Rx MLink software V1.2.0.0 with Ethernet Communication and Trender Measurement Function

2011 Rx MLink Software Now Available

What's new in this update:

- New Ethernet communication Rx, MLink can now be used over a Modbus/TCP network to communicate with Rx devices
- New Trend-recorder signal measurement function (min, max, avg, and peak-peak)
- New Communication layer for faster parameter read/write
- Updated parameter reports
- Updated parameter overview
- Updated parameter management
- Updated demo modes for monitor, status and trender
- Support for firmware v1.67 added
- Updated help file

Rx Ethernet Communication Trend Signal Measurement Function

Click images to enlarge


File: Zip File

Download


Mar 23rd 2011

MVC Plus MLink Software Update

Version 1.1.6.0:

- Support for firmware version 7.20 added

- Minor changes and improvements

File: Zip File (21.6 MB)

Download


Feb 28th 2011

New VMX Pump Jack Application Brochure now available.

Did you know that Motortronics soft starters include dedicated application functions to handle the toughest applications?

Click here to view our low voltage soft starter products.

Click here to view our medium voltage soft starter products.

Soft Starters for Pump Jack Applications

Click here to open document or right mouse click to save document 924 KB (PDF)



Click here to view all available sales literature.




Feb 24th 2011

New VMX Sand and Gravel Application Brochure now available.

Did you know that Motortronics soft starters include dedicated application functions to handle the toughest applications?

Click here to view our low voltage soft starter products.

Click here to view our medium voltage soft starter products.

Soft Starters for Sand and Gravel Applications

Click here to open document or right mouse click to save document 975 KB (PDF)



Click here to view all available sales literature.


Feb 7th 2011

MVC Plus MLink Software Update

Version 1.1.5.1:

- Updated controls for monitor panel, diagnostics panel and trend-recorder.

File: Zip File (21.6 MB)

Download


Jan 26th 2011 : VMX-H - Updated Brochure Now Available

VMX Soft Starter Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.

VMX-H "Heavy Duty"

Configured Soft Starter

Click here to open document or right mouse click to save document 1.3 MB (PDF)




Jan 17th 2011

2011 Rx MLink Software Now Available

The 2011 edition of the Rx MLink software is now available for the Rx Motor Protection Relay.

This update adds a new long term trending option to the software that allows users to trend multiple Rx motor protection relays for weeks, months or years.

File: Zip File

Download


Jan 13th 2011

Updated Rx Motor Protection Brochure Now Available

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.

Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 4.66 MB (PDF)


Dec 27th 2010 : VMX Compact Soft Starter - Updated Brochure Now Available

Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.

VMX Compact Starter

Sales Brochure

Click here to open document or right mouse click to save document 5.02 MB (PDF)


Oct 27th 2010

Updated Brochure is now available for the MVC Plus

MVC Plus Medium Voltage Starter

Click here to open document or right mouse click to save document 2.64 MB




Sep 28th 2010

DXT MLink Software Update

Version 1.0.1.0:

- Updated longterm trending for 24Hrs

File: Zip File (20.7 MB)

Download


Sep 27th 2010

MVC Plus MLink Software Update

Version 1.1.5.0:

- Updated longterm trending for 24Hrs

File: Zip File (21.9 MB)

Download


Aug 21st 2010

MVC Plus MLink Software Update

Version 1.1.4.0:

- Dedicated support added for V6.86
- Added Windows 7 hi-resolution icons for program and project
- Project file open function from external location added

File: Zip File (21.4 MB)

Download


Aug 20th 2010

A VMX Series MLink Update is Now Available

VMX Series MLink Software V1.1.1.0

VMX Series MLink Software

The VMX Series MLink software allows users to program, monitor, diagnose and startup a VMX Soft Starter.

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet Application Setup Wizard

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 4 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Communication connection for serial and USB

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates



File: Zip File (17.6 MB)

Download


Aug 13th 2010

New DXT Series MLink Software Now Available.

DXT Series MLink Software

The DXT Series MLink software allows users to program, monitor, diagnose and startup the DXT Advanced Digital Soft Starter.

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet History log with up to 64 Events including date and time stamp

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 4 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Communication connection for serial and USB

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates

File: Zip File (20.7 MB)

Download


Aug 2nd 2010

MVC Plus MLink Software Update

Version 1.1.3.0:

- Support added for V7.12
- Added improvements, text changes

File: Zip File (21.4 MB)

Download


Jul 7th 2010

MVC Plus MLink Software Update

Jul 7th 2010: What's new in Version 1.1.2.0:

- Trend-recorder inprovements for zoom, cursor and normal operation
- Added Automatic Parameter Save Function
- Various small improvements & fixes

File: Zip File (21.4 MB)

Download


Jul 5th 2010

Updated Rx MLink Software Now Available

An MLink software update is now available for the Rx Motor Protection Relay, V1.04.00, support has been added for the new firmware version 1.66.

File: Zip File (16.2 MB)

Download

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor

Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 1.86 MB (PDF)


May 27th 2010

MVC Plus MLink Software Update

May 27th 2010: What's new in Version 1.1.1.0:

- Serial Parameters Page 11 now independent from project
- Highlighted report setpoint page titles
- Temperature engineering units now show °C instead of C for parameters and status
- Improved graphics menu bar
- Updated help file
- Various small improvements & fixes

File: Zip File (21.4 MB)

Download

May 14th 2010

MVC Plus MLink Software Update

An update is now available for the MVC Plus MLink Software. This update includes new advanced automatic update functionallity and improved MVC Plus Multi System Network Communication.

File: Zip File (21.4 MB)

Download


May 12th 2010

NEW MV CONTACTOR BROCHURES NOW AVAILABLE FOR 7.2kV and 12 kV

7.2kV Contactor

Medium Voltage Contactors

Click here to open document or right mouse click to save document 833 KB (PDF)

12kV Contactor

Medium Voltage Contactors

Click here to open document or right mouse click to save document 751 KB (PDF)



Medium Voltage Contactor - 7.2 kV Class

Motortronics 7.2kV Class, ‘Non-Latching’ (C) and ‘Latching’ (CJ) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 7.2 kV and can be used for continuous AC operating currents of up to 400, 630 or 800 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models CJ).

More Information 7.2kV Contactor

Medium Voltage Contactor - 12 kV Class

Motortronics 12kV Class, ‘Non-Latching’ and ‘Latching’ (L) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 12 kV and can be used for continuous AC operating currents of up to 400 or 630 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models L).

More Information 12kV Contactor


Apr 22nd 2010

New Medium Voltage Control Power Transformers are now available for input voltages ranging from 7.2 to 15kV

We are pleased to announce that the new Models PTG5-1-110 & PTG5-2-110 and Models PTW5-1-110 & PTW5-2-110 Control Power Transformers.

Click here for more information







Medium Voltage Transformers Brochure

5kV, 7.2kV and 15kV Class

Click here to open document or right mouse click to save document 1.02 MB (PDF)


Apr 19th 2010

MVC Plus MLink Software Update

An update is now available for the MVC Plus Link Software. This update adds long-term trending funtion to the software.

File: Zip File (21.4 MB)

Download


Apr 9th 2010

MOTORTRONICS INTRODUCES NEW MEDIUM VOLTAGE CONTACTORS FOR 7.2 and 12 kV

Medium Voltage Contactor - 7.2 kV Class

Motortronics 7.2kV Class, ‘Non-Latching’ (C) and ‘Latching’ (CJ) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 7.2 kV and can be used for continuous AC operating currents of up to 400, 630 or 800 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models CJ).

Datasheet 7.2kV Contactor (PDF 237 kB)

Non-Latching (C) - uses constant-on electromagnetic coils to close, and hold closed the vacuum bottle contacts. When the power to the electromagnetic coil is removed, the vacuum chamber contacts spring open (termed as; electrically held contacts or non-latching contacts).

Latching (CJ) - uses separate coils and mechanisms to both close and open the vacuum bottle contacts (termed as; mechanically held or latching, contacts).

RATED
CURRENT

RATED
VOLTAGE

PART NUMBER
NON-LATCHING (C)

PART NUMBER
LATCHING (CJ)

400A

7.2kV

34-400-3-7200C

34-400-7200-CJ

630A

7.2kV

34-630-3-7200C

34-630-7200-CJ

800A

7.2kV

34-800-3-7200C

34-800-7200-CJ




Medium Voltage Contactor - 12 kV Class

Motortronics 12kV Class, ‘Non-Latching’ and ‘Latching’ (L) Series of medium voltage three-phase indoor vacuum contactors can be used in power systems with a rated voltage of up to 12 kV and can be used for continuous AC operating currents of up to 400 or 630 amperes. Control power for the design is 120VAC, with an external interposing relay consisting of DC-rated contacts required to operate the closing and opening circuits of the contactor (Latching models L).

Datasheet 12kV Contactor (PDF 216 kB)

Non-Latching - uses constant-on electromagnetic coils to close, and hold closed the vacuum bottle contacts. When the power to the electromagnetic coil is removed, the vacuum chamber contacts spring open (termed as; electrically held contacts or non-latching contacts).

Latching (L) - uses separate coils and mechanisms to both close and open the vacuum bottle contacts (termed as; mechanically held or latching, contacts).

RATED
CURRENT

RATED
VOLTAGE

PART NUMBER
NON-LATCHING

PART NUMBER
LATCHING (L)

400A

12kV

34-400-3-12000

34-400-12000L

630A

12kV

34-630-3-12000

34-630-12000L

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers, Control Power Transformers and Contactors

Mar 23rd 2010

Updated Rx MLink Software Now Available

A MLink software update is now available for the Rx Motor Protection Relay, V1.03.10.

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.



Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 4.66 MB (PDF)

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.




Rx Motor Protection
Click here to open document or right mouse click to save document
User Manual

ZCT Option
Click here to open document or right mouse click to save document

Zero Sequence GF CT Option

Installation and Info Sheet


Rx Series MLink Programming Software
Click here to download file





Mar 16th 2010

New Soft Starter Application Brochures now available.

Dedicated soft starter brochures are now available for pumping, conveyor and compressor applications.

Did you know that Motortronics soft starters include dedicated application functions to handle the toughest applications?

Click here to view our low voltage soft starter products.

Click here to view our medium voltage soft starter products.

Soft Starter Dedicated Application Brochures

Soft Starters for Pumping Applications

Click here to open document or right mouse click to save document 1 MB (PDF)

Soft Starters for Compressor Applications

Click here to open document or right mouse click to save document 1.08MB (PDF)

Soft Starters for Conveyor Applications

Click here to open document or right mouse click to save document 1.12 MB (PDF)


Mar 12th 2010

Control Power Transformers 7.2kV

We are pleased to announce that the CPT3 Control Power Transformer is now recognized up to 7.2kV (Maximum Primary Voltage).

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers

Medium Voltage Transformers Brochure

5kV, 7.2kV and 15kV Class

Click here to open document or right mouse click to save document 1.02 MB (PDF)


Feb 12th 2010

VCM Sensorless Vector AC Drive MLink Software Update Now Available

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector Drive

File: Zip File (18.9 MB)

Download


Feb 4th 2010

MVC Plus MLink Software Update

A maintenance release is now available for the MVC Link Software.

File: Zip File (21.4 MB)

Download


Download Click here for our Ethernet Communication Options

Download Ethernet Communiction Diagram (PDF 110KB)


Jan 29th 2010

MVC Link Software

A maintenance release is now available for the MVC Link Software.

File: Zip File (21.1 MB)

Download


Jan 19th 2010

RX Preventive Maintenance System accessible via your web-browser*

Our Rx Motor Protection Relay in combination with our VS1 device can be used for Motor preventive maintenance. View real-time energy data-logging, fault status and maintenance status via your web-browser.

Preventive Maintenance

Setup maintenance thresholds
E-mail motor data and maintenance information
Long-term Energy Trending
All information accessible via standard web-browser*

Monitoring

Customizable Monitor Pages with up to 20 Signals per Page
Select from Predefined System Signals
Create Custom Signals with Custom Scaling, Description and Units

Trending & Data Logging

Log up to 64 Signals with Date and Time Stamp
Configurable Sample Rate with Data Logging up to 3 Years
Export or E-Mail Trend Data
Offload Data to FTP Server

Alarm Monitoring

Define up to 64 Alarms
Alarm History Overview with Date and Time Stamp
Alarm Notification via SMS* or E-mail*



* E-mail / FTP access requires Network Connection / SMS requires GSM/GPRS Modem

RX Motor Protection

Preventive Maintenance

Click here to open document or right mouse click to save document 1.03 MB (PDF)

BulletDownload Brochure (PDF, 489KB)

Click Image for information about the Motortronics 64-VS1 Module




Jan 15th 2010

Updated Rx User Manual and ZCT Option Info Sheet Now Available



Brochure

RX Motor Protection

Click here to open document or right mouse click to save document 4.66 MB (PDF)

Take your motor protection to a new level. The RX Series provides more than just solid state overload or power protection relays. By using features previously found only in large expensive Motor Protection Relays, the RX Series allows even small to medium sized motor applications to be protected by the best technology available, yet at a price affordable to all.




Rx Motor Protection
Click here to open document or right mouse click to save document
User Manual

ZCT Option
Click here to open document or right mouse click to save document

Zero Sequence GF CT Option

Installation and Info Sheet


Rx Series MLink Programming Software
Click here to download file





Dec 31st 2009

A New Brochure is now available for our 600V Low Voltage Transformers.

Low Voltage - 600V

Transformers

Low Voltage Transformers

Click here to open document or right mouse click to save document 1.29 MB (PDF)



Current, Voltage and Control Power Transformers

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers

CT 600V Non-Ansi Rated

Window Type

Current Transformers

Click here to open document or right mouse click to save document 770 KB (PDF)

CT 600V Ansi Rated

Window Type

Current Transformers

Click here to open document or right mouse click to save document 888 KB (PDF)

Medium Voltage - 5kV

Transformers

Med. Voltage Transformers

Click here to open document or right mouse click to save document 1.02 MB (PDF)

.


Dec 16th 2009 : VMX Compact Soft Starter

Updated VMX User Manual Now Available

Flexibility of Control
Multiple ramp profiles, Pump-FlexTM Decel, process control timers and advanced motor protection make the VMX Series soft starter adaptable to a wide variety of AC motor applications... no need for add-on modules or costly auxiliary devices.

Compact packaging has become critical in more and more electrical installations. The VMX Series meets this need without compromising features and ratings. By using a highly engineered packaging design and the latest generation microprocessor, all the control and protection features you need are in the VMX Series. Narrow and shallow dimensions are perfect for integrating the VMX Series into motor control centers (MCCs), pump control panels, and retrofit starter enclosures.

Integral Bypass Contactors are standard on all sizes and provide maximum efficiency of panel space while maintaining the Motortronics reputation for being able to soft start most any load. The VMX Series is the only fully integrated, compact, world-class design offering uncompromised power and control capabilities.



VMX Series

User Manual

Click here to open document or right mouse click to save document 2.24 MB (PDF)

VMX Compact Starter

Sales Brochure

Click here to open document or right mouse click to save document 4.65 MB (PDF)


Dec 8th 2009 : VCM Series Sensorless Vector AC Drive

New VCM User Manual Now Available

VCM Series is a compact, cost-effective drive with features typically found only in more complex and expensive AC drives. This full featured sensorless vector drive is recognized for being simple to set up, program and operate. Available in ratings from 0.5 to 75HP, the VCM Series is ideally for nearly any application. The convenient operator panel provides simple, yet informative interface during setup and operation.

The tactile feedback keypad is used for programming the drive and motor speed can be controlled using either the keypad or the handy, built-in potentiometer. The alphanumeric display indicates operation, status and fault read-out and is easily visibile in low ambient light conditions. In addition, LED indicators provide direction of rotation, operating status and drive output information. An optional two-line LCD display is available.



VCM Series AC Drive

User Manual

Click here to open document or right mouse click to save document 2.13 MB (PDF)

VCM Series

AC Drive

Click here to open document or right mouse click to save document 2.13 MB (PDF)




Nov 25th 2009

Updated MLink software versions are now available for the MVC Plus Series and VMX Series.

VMX Series MLink Software V1.02.00

File: Zip File (17.6 MB)

Download

MVC Plus Series MLink Software V1.00.07

File: Zip File (21.1 MB)

Download


Nov 3th 2009

New Brochures are now available for the Medium Voltage Transformers

Medium Voltage Transformers

Voltage Transformers

Click here to open document or right mouse click to save document 1.02 MB (PDF)



Current, Voltage and Control Power Transformers

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers.


Oct 24th 2009

New Brochures are now available for the CT 600V Ansi / non-Ansi Rated Window Type

CT 600V Non-Ansi Rated Window Type

Current Transformers

Click here to open document or right mouse click to save document 770 KB (PDF)

CT 600V Ansi Rated Window Type

Current Transformers

Click here to open document or right mouse click to save document 888 KB (PDF)



Current, Voltage and Control Power Transformers

Click here to view our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers.


Oct 14th 2009

New Version RX Programming Software with support for Zero Sequence Ground Fault CT Option (ZCT)

Program, Diagnose and Monitor the RX Motor Protection Relay with the RX M-Link Software

RX Series M-Link Software

The RX Series M-Link software allows users to program, monitor, diagnose and startup the RX Motor Protection Relay

File: Zip File (16.2 MB)

Download


Sep 29th 2009

VCM Sensorless Vector AC Drive MLink Software Now Available

This software offers users ease of programming, startup and trouble-shooting for the VCM Sensorless Vector Drive

File: Zip File (18.2 MB)

Download

Software features include:

Bullet Basic and Advanced Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet Advanced reporting functions

Bullet PID Tuner

Bullet Application Setup Wizard

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 3 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor, operator and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates


Sep 22nd 2009

MVC Plus Series MLink Software Update Now Available - Now with built-in Warranty Registration

The MVC Plus Series M-Link software allows users to program, monitor, diagnose and startup the MVC Plus.

File: Zip File (21.1 MB)

Download


Sep 14th 2009

New Brochure now available for the MT Series AC Drive.

MT Series

AC Drive

Click here to open document or right mouse click to save document 2.13 MB


Sep 1st 2009

MVC Plus Series MLink Software Update Now Available.

The MVC Plus Series M-Link software allows users to program, monitor, diagnose and startup the MVC Plus.

File: Zip File (19.2 MB)

Download


Aug 26th 2009

New Brochures are now available for the VCM Sensorless Vector AC Drive, ME2 Micro AC Drive and MHW Heater Controller.

VCM Series

AC Drive

Click here to open document or right mouse click to save document 2.13 MB (PDF)

ME2 Series

AC Drive

Click here to open document or right mouse click to save document 1.04 MB (PDF)

MWH Series

Motor Winding Heater

Click here to open document or right mouse click to save document 860 KB (PDF)


Aug 4th 2009

New Green Energy Management Brochures for Soft Starer and Motor Protection are now available

VMX Compact Starter

Green Energy Management

Click here to open document or right mouse click to save document 782 KB (PDF)

RX Motor Protection

Green Energy Management

Click here to open document or right mouse click to save document 769 KB (PDF)


Jul 30th 2009

New MVC Plus Series MLink Software Now Available.

MVC Series M-Link Software

The MVC Plus Series M-Link software allows users to program, monitor, diagnose and startup the MVC Plus.

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet History log with up to 64 Events including date and time stamp

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 3 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Communication connection for serial and USB

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor, operator and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates

File: Zip File (21.1 MB)

Download




Jul 29th 2009

NEW Brochures are now available for the MVC Plus, VMX, VMX-H and Rx

MVC Plus

Medium Voltage Starter

Click here to open document or right mouse click to save document 2.54 MB

VMX Compact Starter



Click here to open document or right mouse click to save document 4.65 MB (PDF)

VMX-H "Heavy Duty"

Configured Soft Starter

Click here to open document or right mouse click to save document 1.3 MB (PDF)

RX Motor Protection



Click here to open document or right mouse click to save document 4.66 MB (PDF)


Jul 27th 2009

Current, Voltage and Control Power Transformers

Our complete line of 600V Ansi and Non-Ansi Rated Current Transformers, Low Voltage Class and Medium Voltage Class Transformers and Control Power Transformers.



LinksQuick Links

Bullet CT 600V Non-Ansi Rated Overview

Bullet CT 600V Ansi Rated Overview



LinksQuick Links

Bullet VT 600V Ansi Rated Overview

LinksQuick Links

Bullet Medium Voltage Transformers Overview


Apr 28th 2009

2009 M-Link Software Updates are now available for:

RX Series M-Link Software

File: Zip File (16.2 MB)

Download

VMX Series M-Link Software

File: Zip File (14.7 MB)

Download

VCM Series M-Link Software

File: Zip File (18.2 MB)

Download

NEW: MVC Plus Series M-Link Software

File: Zip File (21.1 MB)

Download


Mar 4th 2009

New MVC Plus 12 Page Color Brochure Now Available

The MVC Plus Medium Voltage Series Soft Starter is designed to start AC motors in any fixed speed application. It provides maximum protection with "True Thermal Modeling," while allowing smooth, stepless control of acceleration and deceleration. The MVC Plus Series guarantees power control and protection for your most important assets.

Click to download brochure

BulletDownload Brochure (PDF, 2.52 MB)


Oct 24th 2008
RX Programming Software. Program, Diagnose and Monitor the RX Motor Protection Relay with the RX M-Link Software.

RX Series M-Link Software

The RX Series M-Link software allows users to program, monitor, diagnose and startup the RX Motor Protection Relay

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet Application Setup Wizard

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 3 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Communication connection for serial and USB

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor, operator and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates

File: Zip File (16.2 MB)

Download




Oct 15th 2008
VMX Programming Software. Program, Diagnose and Startup a VMX Soft Starter with the VMX M-Link Software.

VMX Series M-Link Software

The VMX Series M-Link software allows users to program, monitor, diagnose and startup a VMX Soft Starter.

Software features include:

Bullet Parameter editing and commissioning

Bullet Parameter compare functions

Bullet Parameter settings export to popular file format (PDF, XLS, RTF, etc...)

Bullet Application Setup Wizard

Bullet Visual Programming, point and click on visual terminal strip

Bullet Monitor Panel with 3 programmable signals

Bullet Trend-recoder with 6 programmable channels, storage, triggering and playback mode

Bullet Status and Diagnostics Panel for quick drive status and fault history overview

Bullet Communication connection for serial and USB

Bullet Built-in comprehensive help and product user manual

Bullet Multi-drop network support for trend-recorder, monitor, operator and diagnostics panel.

Bullet Demo modes for all interactive functions.

Bullet Built-in Automatic Software Updates

File: Zip File (17.6 MB)

Download




Oct 2nd 2008
Save Energy by using Motortronics AC Drives for your Fan and Pumping Applications. Estimate savings with our Energy Estimator Software.

Energy Estimation Software for Fan and Pumping Applications. This program estimates energy savings achieved when using the Motortronics Series of AC Drives instead of conventional control methods for fan and pumping applications. The results can be viewed in graphical format and text format and the software has built-in functions to generate an energy estimation report especially designed for consultants.

Motortronics AC Drives can be setup to match your required fan and pump curve.

Energy Estimation Software features include:

Bullet Estimate energy savings for fan and pump applications up to 5000 HP

Bullet 5 Easy steps to complete your estimation

Bullet Customer information option (prepare report directly for your customer)

Bullet Company incentive function

Bullet Adjustable efficiency for all standard control methods

Bullet 2 fully customizable additional control methods (title, efficiency, duty cycle)

Bullet Fully customizable estimation report, custom letterhead and company information

Bullet Multiple export formats (RTF, PDF, TXT, HTML etc..)

Bullet Formulas page, contains industry formulas with automatic calculation



VCMSOFT

File: Zip File (10.9 MB)

Download



Aug 25th 2008
New Website Launched
Motortronics is pleased to annouce the lauch of its new corporate website to better serve our customers.

Oct 14th 2007
AC DRIVE SOFTWARE

Updated MT and VCM Drive Software ready for download.

Click here for the Motortronics Software Section



July 31st 2007
Motortronics 13.8kV Medium Voltage Soft Starters Key Component of NYC-DEP WWTP Project

The scope of this upgrade project included nine (9) 13.8kV MVC Plus Series soft starters for controlling the 2000 horsepower motors driving the aeration blowers used in the wastewater treatment process.

Click here for more information on Motortronics Medium Voltage Soft Starters



June 6th 2007
Advanced Motor Protection - The RX Series

Motortronics has recently launched the RX Series, the advanced Motor Protection Relay...

Click here for more information on the Motortronics RX Series



Bullet June 1st 2007
The MT Series – High Performance AC Drive

The MT Series drive defines ease of use for variable speed AC drives and simplifies complex applications with customizable capability. Reliable, expandable and easy to control, it saves time and money for machine builders, panel builders and system integrators.ith

Click here for more information on the Motortronics MT Series
